FLOW RATE TO 424 LPM (112 GPM)
MAX PRESSURE = 8.6 BAR (125 PSI)
WETTED HOUSINGS
(Water Chambers and Manifolds)
| Material | Ship Wt |
| Aluminum | 33 kg (72 lbs) |
| Alloy C | 31 kg (68 lbs) |
| Stainless Steel | 28 kg (62 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
| Center Section | Aluminum, Stainless Steel |
| Air Valve | Aluminum, Stainless Steel |
MAXIMUM SUCTION LIFT CAPABILITY
6.9 m (22.7')
MAXIMUM DIAMETER SOLIDS
7.9 mm (5/16")
ENGINEERING OPERATION & MAINTENANCE MANUAL
DIMENSIONAL DRAWINGS (CAD REQUIRED)
GENERAL SPECIFICATIONS
