FLOW RATE TO 212 LPM (56 GPM)
MAX PRESSURE = 8.6 BAR (125 PSIG)
WETTED HOUSINGS
(Liquid Chambers and Manifolds)
| Material | Ship Wt |
| Aluminum | 15 kg (34 lbs) |
| Ductile Iron | 26 kg (57 lbs) |
| Stainless Steel | 28 kg (61 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
| Center Section | Aluminum |
| Air Valve | Aluminum |
MAXIMUM SUCTION LIFT CAPABILITY
5.5 m (18.2') Dry
MAXIMUM DIAMETER SOLIDS
6.4 mm (1/4")
