FLOW RATE TO 1211 LPM (320 GPM)
MAX PRESSURE = 8.6 BAR (125 PSI)
WETTED HOUSINGS
(Water Chambers and Manifolds)
| Material | Ship Wt |
| Ductile Iron | 223 kg (492 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
| Center Block: | Aluminum, Polypropylene |
| Air Valve: | Aluminum, Polypropylene |
| Air Chambers: | Aluminum |
MAXIMUM SUCTION LIFT CAPABILITY
4.3 m Dry (14.1')
8.6 m Wet(28.4')
MAXIMUM DIAMETER SOLIDS
35 mm (1-3/8")
ENGINEERING OPERATION & MAINTENANCE MANUAL
DIMENSIONAL DRAWINGS (CAD REQUIRED)
