FLOW RATE TO 62.8 LPM (16.6 GPM)
MAX PRESSURE = 8.6 BAR (125 PSI)
WETTED HOUSINGS
(Water Chambers and Manifolds)
| Material | Ship Wt |
| Aluminum | 6 kg (13 lbs) |
| 316 S.S. | 9 kg (20 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
| Center Section | Aluminum |
| Air Valve | Aluminum |
MAXIMUM SUCTION LIFT CAPABILITY
5.9 m (19.3')
MAXIMUM DIAMETER SOLIDS
1.6 mm (1/16")
ENGINEERING OPERATION & MAINTENANCE MANUAL
DIMENSIONAL DRAWINGS (CAD REQUIRED)
GENERAL SPECIFICATIONS
